NO Parts_No. Parts_Name Q_ty Remarks Change Compati
1 KLJ-MC202-00 COVER 12/24,F.S. 1
2 KLJ-MC131-00 SPROCKET ASSY. 1
3 91312-03018 BOLT HEX,SOCKET HEAD 1
4 KLJ-MC2E1-00 GEAR,IDLE F1 ASSY. 1
5 KLJ-MC2E2-00 GEAR,IDLE F2 ASSY. 1
6 KLJ-MC1E3-00 GEAR,IDLE F3 ASSY. 1
7 KLJ-MC1E4-00 GEAR,IDLE F4 ASSY. 1
8 KLJ-MC238-00 GEAR 1216,DRIVEN 1
9 KLJ-MC23G-00 SHAFT 12/24,D.G. 1
10 KLJ-MC23A-00 SHIM 12/24,SPROCKET 1
11 KLJ-MC2EH-00 BEARING 6-10 3
12 KLJ-MC2E8-00 FRANGE 12/24,WASHER 1
13 KLJ-MC2E9-00 WAVE WASHER,D.G. 6-8 1
14 KLJ-MC13P-00 SPACER,F3 1
15 KHJ-MC251-00 GEAR,IDLE P1 1
16 KHJ-MC252-00 GEAR,IDLE P2 1
17 KHJ-MC253-00 GEAR,IDLE P3 1
18 KHJ-MC254-00 GEAR,IDLE P4 1
19 KHJ-MC256-00 ROLLER, PEEL OFF 1 1
20 KHJ-MC258-01 COVER,IDLE GEAR 1 1
21 KHJ-MC259-00 COVER,IDLE GEAR 2 1
22 KHJ-MC25A-00 SUB-ROLLER,1 2
23 KHJ-MC25E-00 COVER,IDLE GEAR 3 1
24 90115-2AJ008 BOLT, HEX. SOCKET HEAD 2
25 KHJ-MC266-00 BLOCK,P/O TOOTH 1 1
26 KHJ-MC46T-00 BOLT HEX. S/H LOW 1
27 KHJ-MC269-00 ROLLER,P/O 2 1
28 KHJ-MC26A-00 SHAFT,P/O LEVER 1 1
29 90440-01J030 CIRCLIP 1
30 90990-09J008 SCREW,FLAT HEAD 16
31 KLJ-MC1A2-00 COVER,BOX EL 1
 |
